A sensor design based on the principle of laser ranging to measure the thickness of sea oil spill
Lichen Zhang

Yazhou Bay Innovation Institute/ College of Marine Science and Technology, Hainan Tropical Ocean University, Sanya Hainan,572022；

Abstract: This study aims to design a marine oil film thickness measurement sensor based on pulsed laser ranging technology to address the potential ecological threats posed by oil spill incidents in marine environments. By employing an advanced measurement approach, the sensor continuously monitors the thickness of oil films on the ocean surface, offering an effective means for environmental protection and oil spill emergency response. The research team conducted a comprehensive analysis of key influencing factors and mechanisms during the measurement process, providing theoretical support for the sensor's design and application. The sensor system comprises five main components: the Sensor Control Unit, Laser Ranging Unit, Wireless Serial Communication Unit, Upper Computer Data Reception Unit, and Upper Computer Data Processing Software. Through module testing and measurements in an experimental water tank, the study validates the measurement accuracy of the sensor. Experimental results demonstrate that the relative error remains within the range of 2% to 3% across various oil film thickness measurements, confirming the feasibility of the sensor in measuring thicker oil films in practical applications. Further validation in actual water tank experiments underscores the sensor's performance and stability, thereby offering robust support for marine environmental monitoring and emergency response efforts.

Keywords: Marine oil spill; oil film thickness measurement;  pulsed laser ranging technology;  environmental protection;  sensor design

References

[1]Gao Antai Overview of offshore oil spill monitoring systems. China New Telecommun. 2021, 23, 13–14.

[2]Zhu Linchao; Wang Dongguang; Gu Jiapeng Emergency handling of Marine oil spill pollution accidents. China Water Transp. 2019, 19, 137–138.

[[3]Zhang Haokeng Analysis of pollution effects of oil spills at sea. Resour. Econ. Environ. Prot. 2018, 121–122, doi:10.16317/j.cnki.12-1377/x.2018.12.088.

[4]Fang Jinbiao Research and construction of offshore oil film detection system. master, Daliann Maritime University, 2014.

[5]SONG Sha-sha; AN Wei; LI Jian-wei; ZHAO Yu-peng; JIN Wei-wei Review on the Methods for Assessment of Marine Oil Spill Volume. Coast. Eng. 2017, 36, 83–88.

[6]Brown, C.E.; Fingas, M.F. Development of Airborne Oil Thickness Measurements. Mar. Pollut. Bull. 2003, 47, 485–492, doi:10.1016/S0025-326X(03)00203-0.

[7]Pelyushenko, S.A. Microwave Radiometer System for the Detection of Oil Slicks. Spill Sci. Technol. Bull. 1995, 2, 249–254, doi:10.1016/1353-2561(95)00031-3.

[8]Abdul-Wahab, S.A. In Situ Device for Detection of Oil Spill in Seawater. Electroanalysis 2006, 18, 2148–2152, doi:10.1002/elan.200603617.

[9]Sun, C.; Yu, L.; Sun, Y.; Yu, Q. Scanning White-Light Interferometer for Measurement of the Thickness of a Transparent Oil Film on Water. Appl Opt 2005, 44, 5202–5205.

[10]Kukhtarev, N.; Kukhtareva, T.; Gallegos, S.C. Holographic Interferometry of Oil Films and Droplets in Water with a Single-Beam Mirror-Type Scheme. Appl. Opt. 2011, 50, B53, doi:10.1364/AO.50.000B53.

[11]Lu Yingcheng; Tian Qingjiu; Li Xiang Remote sensing retrieval theory of oil film thickness based on two-beam interference model of oil slick film. Sci. Sin. 2011, 41, 541–548.

[12]YE Zhou; LIU Li; WEI Chuan-xin; GU Qun; AN Ping-ao; ZHAO Yue-jiao; YIN Da-yi Experimental Methods and Result Analysis of a Variety of Spectral Reflectance Properties of the Thin Oil Film. Spectrosc. Spectr. Anal. 2015, 35, 1695–1699.

[13]Wu Di; Lu Qieni; Chen Xi; Ge Baozhen Analysis on Measurement Range and Precision of the Oil Film Thickness Measurement Sensor Based on Differential Laser Trigonometry. J. Tianjin Univ. Technol. 2013, 46, 998–1002.

[14]Li Ying; Fang Jinbiao; LIU Yu; LIU Bing-xin The measurement system technology of offshore oil film thickness. Mar. Environ. Sci. 2014, 33, 777–780, doi:10.13634/j.cnki.mes.2014.05.023.

[15]Feng Bo Research on pulsed laser ranging technology. Electron. World 2021, 63–64, doi:10.19353/j.cnki.dzsj.2021.08.031.

[16]Sha Lei Study on the influence of parameters of pulsed laser receiving system on its ranging ability. China Metrol. 2020, 98–99, doi:10.16569/j.cnki.cn11-3720/t.2020.12.042.

[17]GAO Yong; HUANG Feibo; CHEN Lida Study on the Ranging Ability of Pulse Laser Rangefinder. Electron. Prod. Reliab. Environ. Test. 2020, 38, 44–47.
